Description
The Matrix MX530 Professional Single Sided Laminator will enable you to bring affordable single sided lamination in-house. Perfect for those businesses that want to print on demand but are currently restricted by the need to outsource their lamination. Ideal for short to medium size runs there is no need to pay costly set up charges, and no delay! Solidly constructed and great for a wide range of applications. the Matrix 530 is the best value single sided laminator on the market.
Features of the Matrix MX530
- Laminates up to SRA2 (Max film width 510mm)
- Takes roll lengths of up to 1000m
- Suitable for gloss, matt and soft touch film
- High speed performance
- Built in separator – work comes off finished – ready for guillotine
- Side lays ensure prints are fed centrally
- Quick set up time
- Semi-automatic feeder
- Suitable for traditional offset and digital prints
- Auto sheet register and overlap system via front guard
- Film thickness 25-32mic * paper thickness 150-400 gsm
- Laminating speed 7 metres per minute (approx) * laminating temperature 80 – 130C
- Power consumption 1560W
- Power supply 220/240v ac 50-60Hz (13 AMP supply)
- Dimensions (W X D X H) 2100 x 840 x 1315mm
- Weight machine 130kg (Stand 64kg)
Auto-Feeder (Optional)
The Auto-Feeders can be fitted to the full pneumatic range of Matrix MX-370 and MX-530 Laminating Systems and completely automate your print finishing workflow. Prints can be loaded ‘on the run‘ for non-stop operation. Aimed at the digital/commercial markets, short-to-mid run business cards, menus, book covers, bespoke prints and more can all be finished faster. Feed prints for lamination, foiling & spot UV effects, the Matrix becomes a truly automated print finishing system.
Film Slitter (Optional)
Designed to make your life more simple. Rather than changing rolls of film for smaller width jobs than the film that is loaded, the slitter will cut down the film to whatever size you require.
Fan System – with AirFlow Technology (Optional)
An add-on accessory, designed exclusively for the Matrix. Laminated sheets collect in the output tray effortlessly.
Flatbook (Optional)
Flatbook enables Perfect Bound and PUR Bound book covers to be laminated both sides and stay perfectly flat. Curl on book covers is a significant problem in the printing industry, mainly overcome by using expensive specialist films. The Flatbook system enables you to use standard OPP film, on all types of stock. It cuts out a channel of film as it laminates, leaving the inside spine unlaminated. This allows the adhesive to stick to the spine and not the laminate. The result is a perfectly bound flat book.
Take-Up Unit (Optional)
An optional take-up unit that sits at the rear of the Matrix. This can be used in conjunction with the Flatbook device and also when using the Matrix to foil and create Spot UV-style effects. It works in perfect synchronisation with the Matrix and neatly collects spare film and foil.
Talk to us right away about using finance to get ahead with laminating.
